| Nama merek: | DLX |
| Nomor Model: | Kawat Paduan FeCrAl 0Cr25Al5 |
| MOQ: | 10KG |
| Ketentuan Pembayaran: | L/C,D/A,D/P,T/T,Western Union |
| Kemampuan Pasokan: | 500 ton per bulan |
| Nomenklatur Paduan Kinerja | 1Cr13Al4 | 0Cr25Al5 | 0Cr21Al6 | 0Cr23Al5 | 0Cr21Al4 | 0Cr21Al6Nb | 0Cr27Al7Mo2 |
|---|---|---|---|---|---|---|---|
| Komposisi Kimia (%) - Cr | 12.0-15.0 | 23.0-26.0 | 19.0-22.0 | 20.5-23.5 | 18.0-21.0 | 21.0-23.0 | 26.5-27.8 |
| Komposisi Kimia (%) - Al | 4.0-6.0 | 4.5-6.5 | 5.0-7.0 | 4.2-5.3 | 3.0-4.2 | 5.0-7.0 | 6.0-7.0 |
| Komposisi Kimia (%) - Re | Sesuai | Sesuai | Sesuai | Sesuai | Sesuai | Sesuai | Sesuai |
| Komposisi Kimia (%) - Fe | Sisa | Sisa | Sisa | Sisa | Sisa | Sisa | Sisa |
| Suhu Layanan Berkelanjutan Maks. Elemen (°C) | 950 | 1250 | 1250 | 1250 | 1100 | 1350 | 1400 |
| Resistivitas pada 20°C (μΩ.m) | 1.25 | 1.42 | 1.42 | 1.35 | 1.23 | 1.45 | 1.53 |
| Kepadatan (g/cm³) | 7.4 | 7.1 | 7.16 | 7.25 | 7.35 | 7.1 | 7.1 |
| Kekuatan Tarik (N/mm²) | 580-680 | 630-780 | 630-780 | 630-780 | 600-700 | 650-800 | 680-830 |
| Perpanjangan saat Putus (%) | >16 | >12 | >12 | >12 | >12 | >12 | >10 |
| Bentuk | Ukuran (mm) |
|---|---|
| Kawat | 0.05-7.5 |
| Batang | 8-50 |
| Pita | (0.05-0.35)*(0.5-6.0) |
| Strip | (0.5-2.5)*(5-180) |
